Answer-Seizure Ratio (ASR) and Average Call Duration (ACD)

Introduction

The answer-seizure ratio (ASR) and average call duration (ACD) are the most commonly used metrics to indicate VoIP route quality. They are mentioned in almost every email, chat, etc. between VoIP providers.

You need to understand and fully utilize them in your business when selecting the best routes from your providers, forecasting call volumes, determining traffic demand, measuring the performance of your infrastructure and fixing things when call quality deteriorates.



Description

ASR (Answer-Seizure Ratio)

ASR is the percentage of the number of successfully connected calls to the number of attempted calls (it is also called the call completion rate):

ASR % = (total number of answered calls / total number of calls) × 100

For example, if there were 156 calls dialed of which 62 were successfully connected, then:

ASR (%) = (62 [successful calls] / 156 [dialed calls]) x 100 = 39.74%



ACD (Average Call Duration)

ACD is a quality metric used by telephony providers. It is the average length of an answered call made over the network:

ACD = duration of all answered calls / number of answered calls

For example, if there were 62 answered calls with a total duration of 145 minutes, then:

ACD = 145 [duration of all answered calls] / 62 [total number of answered calls] = 2.34 minutes



What is normal?

ASR should be at least 40–50%, and anything above 60% would indicate an excellent quality service.

An ACD of 4–5 minutes is considered okay, whereas anything above 6 minutes is excellent.



A high ASR indicates a reliable network, since most calls that are attempted are answered.

A high ACD suggests that few calls are dropped or abandoned due to quality issues.



Low ASR/ACD

ASR

Low ASR values may be caused by:

  • User behavior
  • Busy destination lines
  • Far-end switch congestion (capacity problems at the carrier)

ACD

Expect to see ACD above 3 minutes. A shorter ACD can be an indicator of audio quality problems, causing a customer to hang up if they are very unsatisfied about the call quality, that is the quality of the connection is not good enough for the subscriber to continue the call.

Many factors can reduce call quality to give a low ACD:

  • Congestion
  • Long PDD (Post Dial Delay)
  • Looping
  • FAS (False Answer Supervision – dead air)
  • Echo
  • Jitter (variance in delay)
  • Delay (delays of more than 300 ms decrease ACD)
  • Packet loss
  • Low-quality codecs
  • The capacity (measured in packets per second or PPS) of an Ethernet network can be a bottleneck
  • Too many hops (Session Border Controller passing media through them) will also decrease ACD
  • Traffic profiles can also contribute toward a low ACD



Important considerations

User behavior

Since busy signals and other rejections by the called number, count as call failures, the calculated ASR can vary depending on user behavior.

ASR is an industry standard for measuring network quality. However, it is not very suitable for this task because it affected by user behavior. In other words, if a call is not answered, even though the network is not at fault, the ASR would be reduced since it was an uncompleted call, and this would indicate that quality is low. Because for a given hour of the day, the percentage of unanswered calls is always the same, from day to day, this offset averages out. Carriers monitor the ASR trend and treat it as a relative measurement.



Differences by Destination

It is not trivial to determine quality based on the numbers. For example, ASR and ACD vary by route. A typical ASR to Pakistan is lower than that to France. The reasons for this include the quality of the network and that it’s less likely that a call to Pakistan will be taken by an answering machine.



Differences by point of view

For the same calls, ASR and ACD can be different when measured by the customer and the provider. I will try to explain this with an example using ASR. Imagine a customer makes two calls. One is answered and the other is not. So, the ASR for the user is 50%. These two calls were made using least cost routing with two providers. The first call was instantly handled by the first provider. The second call required both providers and it failed. So, the ASR for the first provider is 50% and for the second provider it is 0%. As you can see, one call attempt by a customer can generate several call attempts for the providers. This difference generates different statistics, so it is very important to keep this in mind when talking about ASR and ACD with your customers and providers.



Other quality metrics worth mentioning

PDD

Post-dial delay (PDD) is the time it takes to receive feedback after a user has finished dialing (after they pressed the dial button on their phone). This feedback can be in the form of a dial tone, a recorded announcement or the call being abandoned. A low PDD means a better user experience. Consumers are generally used to the short PDD of a PSTN and often react negatively when there is a long pause after dialing.

In case of higher PDD, it is expected that there is no dial tone for the subscriber to initiate a call.

PDD should be not more than 4-5 seconds, and anything below 2 is considered excellent.



NER

The best metric to describe network performance is the network effectiveness ratio (NER). It is designed to exclude user behavior and it represents the pure network performance better.

It’s calculated as:

NER = (answers + user busy + ring no answer + terminal rejects) / number of total call attempts (seizures)

It is sad that this metric is not used in the industry as the standard because it is much more suitable compared to the ASR, which includes user behavior and is not a pure network performance metric.



Good to know

Carriers seldom consider ACD when defining SLAs. Their focus is only ASR.

ASR is defined in ITU SG2 Recommendation E.411: “International network management – Operational guidance”.
